Standard Equipment
- Power Front Operated Back Gauge, motorized with fine adjustment handwheel
- Power Ram Depth Control, motorized with fine adjustment handwheel
- Digital Displays for backgauge position and ram position
- All Steel Construction
- CNC 2-axis Color Graphic Computer Control
- Sick 4000 Light Curtain
- Ram accepts standard American Tang tooling, ½" x 5/8"
- Space between Ram Tool Clamps allows for deep box bending
- Bed has slot for standard American Tang tooling
- Bed also has capture clamps for tooling without tang
Options Included
- Sick Model 4000 Light Curtain System
Specifications
- Working Pressure: 44 Tons
- Length of Working Table: 78.7"
- Distance Between Housings: 63.7"
- Throat Depth: 7.8"
- Stroke Adjustment of Ram: 1.96"
- Ram Travel: 3.93"
- Open Height: 12.5"
- Rapid Ram Travel Speed: 2.4" / Sec.
- Rapid Ram Retreat Speed: 2.0" / Sec.
- Backgauge Travel: 24"
- Pressing Speed: Dependent on Tool Load
- Hydraulic Oil Capacity: 36 Gal.
- Motor Horsepower: 7.5 HP
- Net Weight: 7,700 lbs
- Length: 101"
- Width: 60"
- Height: 80"
Options
- Sick Model 4000 Light Curtain System
- Fiessler Akas II Laser Guarding
- Pilz PSENvip LED Safety Guarding
- Training packages at US Industrial showroom or customers site
