Standard Equipment
- Squaring Arm
- High Carbon, High Chrome Shear Blades
- Ball Transfers on Each Table Segment
- Manual Quick Change Blade Gap Adj.
- Squaring Arm, 39.5" from blade to end
- Stroke Counter
- Front-controlled Power Back Gauge
- Blade Guard, Micro Switch Protected
- Hydraulic, Electrical Overload Protection
- Automatic Swing-up on Back Gauge
- Bolt on table segments…quantity of 3
- Hold-downs faced w/anti-mar neoprene
- Swing Beam Design
- Pressure Sensing Hold Downs
- Electric Stroke Adjustment
- Operator Control Console
- Shadow Lighting
- Low Noise Gear Pump
- Support Arms Included
Specifications
- Sheet Size: 126"
- Shearing Capacity: 3/8" Mild Steel @ 65,000 PSI
- Shear Angle: 1 Degree 30’
- No Load Strokes: 10
- Throat Depth: 4.7"
- Adjustment Range of Back Gauge: 0.75" - 36"
- Hydraulic Oil Capacity: 73 Gal
- Main Motor: 20 HP
- Net Weight: 24,250 lbs
- Dimensions (L x W x H): 159" x 80" x 70"
Options
- 3-Axis CNC Programmable Back Gauge
- Touch-screen operated. Controls back gauge depth, blade gap and stroke length. It has a 200 program storage capacity, each program up to 20 steps, and it can be operated in manual or automatic mode.
- Pneumatic Sheet Support
- Material Support/Drop Chute
- 6-Foot Squaring Arm
- 8-Foot Squaring Arm
- 10-Foot Squaring Arm
- 48” Back Gauge; no swing up
- Training packages available at US Industrial showroom or customers site
***Machines are shipped without oil. Please refill the oil before operating the machine. Also remember that the machines must be anchored and leveled***
