SPECIFICATIONS:
Main motor: 2 HP, 220V, single-phase, 5A
Hydraulic pump: 1/2 HP
Coolant pump: 1/8 HP
Blade speed: Variable, 85–265 FPM
Blade size: 108-1/4" L x 1-1/16" W
Floor-to-table height: 38-1/2"
Vise jaws: 12-5/8" D x 5-1/2" H
Max. cutting height: 9"
Head swivel: 45° left, 60° right
Cutting capacities:
90° round: 10"
90° rectangular: 9" H x 12" W
±45° round: 7-7/8"
±45° rectangular: 7" x 7"
+60° round: 4-1/2"
+60° rectangular: 6-1/8" H x 4-1/2" W
Footprint: 27" x 34"
Overall dimensions: 58" W x 30" D x 79" H
Approximate shipping weight: 1032 lbs.
FEATURES:
Hydraulically powered headstock with auto-retract
Hydraulically powered automatic vise with auto-retract
Dual-position quick-release vise with work stop
Variable blade speed
Swiveling head
Auto/manual controls
Centralized control panel
Heavy-duty one-piece steel stand
Double ball-bearing blade guides
Built-in blade coolant system
Quick-change blade
Includes a 108" x 1" x 0.035" blade
South Bend 9" x 12" 2 HP Metal-Cutting Bandsaw
Grizzly Industrial
$7,135.00
- SKU:
- SB1122
- UPC:
- 690550947124
