16” Planer / Jointer 25-216H is the machine for those who need BIGGER capacity! Equipped with a large 16” cutter head and powerful 4HP motor that make quick work in milling the hardest, or widest rough-sawn lumber. A favorite of production shops, the jointer and planer tables are made of heavy, cast iron and machined smooth for efficient movement through the cutters. Unique, one-piece jointer tables easily lift up and out of the way for planer use, or to work on the cutter head. The 25-216H has a 2-row, helical cutter head with 44 four-sided, carbide insert cutters.
Features:
- Helical cutter head with 44 carbide insert cutters. Each indexible insert has four pre-sharpened sides and can be easily changed/rotated if damaged or worn.
- All metal construction with machined table surfaces
- Jointer tables move for full access to cutter heads for knife insert changes
- Sliding safety bar adjusts over jointer knives for best user protection
- Height / Depth gauges clearly indicate cut settings
- 5” Dust port effectively removes chips when planning or jointing
- Front located on/off switches for extra safe machine shut downs
Specifications:
- Motor Horsepower: 4 HP
- Motor Amps: 16
- Motor Volts: 230V, 60 Hz
- Motor RPM: 3,400
- Cutterhead Speed: 5,500 RPM
- Cuts per Minute: 16,500 CPM
- Number of Carbide Inserts (4 Sided): 44
- Carbide Insert Size: 15mm x 15mm x 2.5mm
- Number of Insert Rows: 2
- Cutterhead Diameter: 2-1/2”
- Fence Size: 43-1/4” x 6”
- Fence Tilts: 90° to 135°
- Fence Positive Stops: 90° and 45°
- Planer Maximum Cutting Width: 16”
- Planer Maximum Cutting Height: 8"
- Planer Maximum Cutting Depth: 1/8”
- Planer Wood Feed Rate: 23 SF/MIN
- Planer Table Size: 16-1/8” x 23-1/2”
- Jointer Maximum Cutting Width: 16”
- Jointer Maximum Cutting Depth: 1/8"
- Jointer Table Size: 16” x 31-7/8”
- Jointer Table Height from Floor: 35-1/2”
- Overall Height: 39-1/2”
- Overall Width: 38”
- Overall Depth: 65-1/2”
- Overall Base Size: 25” x 23”
- Dust Port: 1@5”
- Overall Net Weight: 639 lbs.
- Warranty: 5 years
What's Included:
- Outfeed Planer Table
- 5 Year Warranty
