DT45 Dovetail Machine with Manual Clamp 1HP 1Ph 230V
The Powermatic® DT45 manual dovetail machine is used to cut dovetails for drawers and various furniture components. The machine is equipped with a router spindle which allows cutting dovetails of adjustable height. The DT45 can machine four types of dovetails with different pitches. Locking and unlocking of pieces takes place manually by an eccentric clamp.
FEATURES
Four centerlines - 1 In., 1-1/2 In., 2 In. and 2-1/2 In. - create a custom appearance
Manual eccentric clamping will keep boards firm
Eccentric spindle collet for resharpened cutters
Spring loaded carriage makes for smooth, effortless dovetail cutting
Cutter height of 3/16 In. to 3/4 In. accommodates different cutting depths and board thicknesses
Extra large soft grip handle provides positive control and comfort
The precision linear carriage bearings are sealed on both ends to eliminate dust buildup
Visual stylus and template aid in guiding the carriage
SPECIFICATIONS
Acme Tools Brand Name
POWERMATIC
Acme Tools Part Number
1791304
Amperage (A)
16
Assembled Weight (lbs)
380
Blade Length (in)
0
Blade Material
N/A
Blade Type
N/A
California Proposition 65 Warning Required
Yes
Color / Finish
See Photo
Cord Length (ft)
8
Country of Origin
Taiwan
CSA Certified
No
ETL Listed
No
globalTradeItemNumber (GTIN)
00662755505065
Internal Supplier Part #
DT45
Internet Product Code (IPC)
03E8A28F32F
Manufacturer Warranty
5 Year
Maximum Stock Length (in)
31
Minimum Stock Length (in)
0
Motor Horsepower (hp)
1
Overall Height (in)
61
Overall Length (in)
33
Overall Weight (lbs)
380
Overall Width (in)
33
Package Depth
33
Package Height
61
Package Weight
380
Package Weight (lbs)
380
Spindle Speed (RPM)
18500
UL Listed
No
Voltage
115/230 Volts
