NS Maquinas Model DM1100 Z Dross Removal And Graining Machine

1 WIDE BELT HEAD TO REMOVE BURRS & GRAIN SURFACES

CONSISTENT LINEAR FINISH AND BRIGHTER SHINE ON
STAINLESS STEEL, STEEL, OR ALUMINUM PARTS CUT BY
LASER, PUNCHING OR SHEARING

NOTE: ALUMINUM CANNOT BE MIXED W/OTHER MATERIALS

26 TO 72 FEET/SECOND VARIABLE SANDING BELT SPEED
43.3" WORKING WIDTH
4.75" MAXIMUM MATERIAL THICKNESS
2" X 2" MINIMUM PART SIZE
5 - 23 FEET/MINUTE VARIABLE FEED RATE (INVERTER)
7.1" DIAMETER CONTACT ROLLER (55 SHORE)
43.3" X 72.8" BELT
6" DUST EXTRACTION FLANGE

5 HP CONVEYOR MOTOR
15 HP SANDING BELTS MOTOR

FEATURES
- VARIABLE SPEED CONVEYOR AND ABRASIVE BELT - CAN
CLEAN EDGES FROM DROSS AT SLOW FEED RATES
APPLY SURFACE FINISH AT HIGH SPEEDS
- HIGH FRICTION CONVEYOR BELT FOR SMALL PARTS
- CONTACT ROLLER / ABRASIVE BELT
FINE ADJUSTMENT FOR DIFFERENT BELT THICKNESSES
QUICK BELT REPLACEMENT WITH PNEUMATIC TENSIONING
ABRASIVE BELT AUTOMATIC OSCILLATION AND TRACKING
SPRING-LOADED PRESSURE ROLLERS KEEP PART IN PLACE
- CONTROL PANEL
SIMPLE, INTUITIVE DESIGN
ON/OFF FOR CONVEYOR AND ABRASIVE BELTS
POTENTIOMETERS TO ADJUST FEED RATE AND BELT SPEED
DIGITAL AMMETER TO MONITOR ABRASIVE BELT LOAD
SET PART THICKNESS WITH TOUCH PANEL OR HAND WHEEL
