Mitutoyo Dial Indicator Depth Gauge 0-8", 7217S

Mitutoyo

$325.50
(No reviews yet) Write a Review
SKU:
7217S
Availability:
Ships within 1 business day.
Adding to cart… The item has been added

Mitutoyo Dial Indicator Depth Gauge 0-8", Ball Point Contact Element  7217S

Mitutoyo 7217S Dial Depth Gauge, Indicator Type, 0-8" Range, 0.001" Graduation, +/-0.002" Accuracy, 1" Stroke, 2.5" x 0.63" Base

Features:

  • The dial indicator has precision-ground hard-chrome-plated stem with standard AGD 3/8" diameter.
  • Contact point is hardened, ground and chrome-plated steel.
  • Spindle rack, pinions and pivots are hardened stainless steel to insure long wear and continuing accuracy.
  • Bezel is cleanly knurled and smoothly adjustable with a clamping screw for positive settings.
  • Accuracy of dial indicator exceeds Federal Specifications.
  • Includes 1", 2", and 4" rods. Rods can be connected for depth upto 8".
  • Thread size: #4-48".
  • Spindle lifting lever for raising and lowering spindle is maintained under spring pressure.
  • Bottom surface of the base is hardened, ground and lapped for highest degree of flatness.
  • The dial indicator is attached to the base by a clamping screw and is readily interchangeable with any other standard AGD dial indicator.
  • Complete with fitted carrying case.
  • Specifications
    • 0 to 8" Measuring range.
    • 0.001" graduations.
    • 1.0" dial range.
    • Measuring force: 2.0 N or less.
