Laguna Tools IQ Pro 24” X 36” CNC Router - MCNC-IQPROATC
The Laguna IQ PRO WITH ATC Laguna has enhanced the best selling IQ CNC with the introduction of a more powerful handheld control that allows for tool path previewing and a three position automatic tool changer.
Automatic Tool Change, where machines can automatically change between three tools during one program.
Handheld controllers with screens displaying the tool path and the G-code during design.
Motor: 3HP 220V / 30 Amp Single Phase
Spindle: 3HP Industrial single phase Continuous Duty Liquid-Cooled
3 position automatic tool changer uses ISO-20 tool holders
Spindle RPM: 6,000 – 24,000 RPM
Controller: Richauto DSP Hand Held
Ball Screw: On All Axis
Gantry Clearance: 6 inches (Optional 12″ Gantry)
Machine Work Table: 24 inches X 36 inches
Machine Foot Print: 39½ inches X 57 inches
Work Envelope: 24 inches X 36 inches
Weight: 746 lbs.
