Description
- Two gear steps and premium frequency control technology ensure high torque across the entire speed range for powerful machining
- The selected spindle speed is displayed directly on the control panel
- Infinitely variable table feed
- Premium cast-iron machine frame with adjustable dovetail guides on all axes
- Motorized cutter head movement and hand-wheel for exact positioning of head
- Automatic quill feed with 3 gear steps
- Hand-wheel for quill micro-feed
- Digital depth indicator for quill travel
- Tapping unit with adjustable rotation reversal for thread cutting
- Hardened gear racks and shafts for quiet operation and long life
- Rigid base with storage room is included
- Infinitely variable feed on X is included
3-Axis Position Indicator
- More accuracy
- Lower error rate
- Increased productivity
- Resulting in valuable time savings
- For increased productivity
- Easy to read display
- Operator-specific features
- Convenient keyboard layout
- Resolution: 0.0004 / 0.0002"
- Default coordinates
- Axis position is maintained when display is turned off
- Hole circle pattern calculation
- Calculator function
- Storage for 10 tools
- Radius / diameter toggle
- Mm/inch conversion
- Easy expansion and maintenance-free operation
Standard Equipment
- 3-axis position indicator
- base
- table feed TV 1000
- drill chuck 1/2"
- tool-holder bits
- operator manual
Specifications
| Working Area | |
| Table Dimensions | 31" x 9" |
| Drilling Capacity | 2" |
| Guide Width | 5" |
| Shaft Milling | 1.26" |
| Head Elevation | 15" |
| Speed | (2) 75-438 / 438-2500 rpm |
| Number of T-Slots | 3 Positions |
| T-Slots, Width | 0.6" |
| T-Slots, Spacing | 3.1" |
| Travels | |
| Travel X-Axis | 22" |
| Travel Y-Axis | 7" |
| Vertical Milling Head | |
| Spindle Mount | MK 4 / MT 4 |
| Quill Stroke | 5" |
| Quill Diameter | 3" |
| Spindle Nose-To-Table Distance | 18" |
| Throat | 10" |
| Head Swivel Range | ± 45° |
| Drive Capacity | |
| Motor rating main drive | 2 HP |
| Measures and Weights | |
| Overall Dimensions | 49" x 37" x 83" |
| Weight | 1,056 lbs |
