High-speed precision and amazing versatility. This rugged piece of equipment has a belt that operates at any angle, and conforms to curves, angles or circular finishing and grinding operations. Machinists who take great pride in their work prefer the JET Industrial Combination Belt & Disc Finishing Machine
60 grit belt and disc standard on machine
Adjustable dust collector and dust chute
Belt head adjusts vertically and horizontally
Belt operates at any angle
Completely enclosed drums and guarded sanding belt
Fully machined, balanced disc
Large cast iron slotted table
Plain and compound miters are easily obtained by using the standard die cast aluminum miter gauge
Removable upper belt guard for contour finishing
Variable position locks
Specifications
More Information
Stock Number JT9-414551
Model Number J-4200A
Belt Size (W x L) (In.) 6 x 48
Belt Speed (SFPM) 2850
Belt Table Size (In.) 7-3/8 x 14-3/4
Belt Grit 80.0000
Disc Diameter (In.) 12.0000
Disc Speed (RPM) 1,960
Belt Table Tilt (Deg.) 45 Out, 20 In
Disc Table Size (L x W) (In.) 16-1/2" X 9"
Disc Table Tilt (Deg.) 45°
Motor (HP) 1-1/2 HP, 115V, 1Ph
Motor Phase Single
Motor Voltage (V.) 115
Overall Dimensions (L x W x H) (In.) 29 x 19 x 58
Gross Weight (Lbs) 250
Warranty 2 Year
Prop 65 Cancer and Reproductive Harm
Weight (Lbs.) 250
Wheel Diameter (In.) 12
Gross Weight 327.0
