Jet HBS-56MVS, Variable Speed, Mitering 5" x 6" Horizontal Bandsaw, .5HP 115V

Jet Tools

$1,329.00
(No reviews yet) Write a Review
SKU:
JT414558
UPC:
731325727340
Adding to cart… The item has been added

This JET Variable Speed, Mitering bandsaw packs the features in a small package. The exclusive 5x6 Portable Variable Speed Mitering Bandsaw includes a newly designed motor with a 3-step gear transmission for unprecedented torque output. The versatile swiveling head allows precision cuts without the hassle of moving the material.



Features:

  • Heavy duty casted head for years of sawing
  • New DC motor with 3-step geaer transmission increases torque output
  • Ball bearing supported blade wheel
  • CSA/US: Following strict guidelines and electrical requirements, this JET saw is CSA/US certified
  • Blade is fully guarded
  • Automatic shut-off after cut
  • Head swivels for a maximum cut at 45° & 60°
  • Variable Speed gives you the ability to cut various materials
  • Hardened Ferrous 82-130 SFPM
  • Ferrous 130-180 SFPM
  • Non-Ferrous, Plastic, Wood 180-230 SFPM
  • Quick speed changes with the turn of a dial, no more belt changes
  • Fully adjustable ball bearing blade guides
  • Front legs feature leveling pads
  • Wheels come standard for ease of movement around your shop



Specifications:

  • Round at 90 Degrees (In.)5
  • Round at 45 Degrees (In.)3-3/4
  • Rectangle at 90 Degrees (In.)5 x 6 , 2 x 6
  • Rectangle at 45 Degrees (In.)3-3/4 x 2-1/3
  • Rectangle at 60 Degrees (In.)1-1/4 x 1-3/4 , 5 x 1-3/4
  • Throat Depth (In.)5
  • Vise Swivels (Deg.)0 - 60
  • Blade Speeds (SFPM)Variable, 80-230
  • Blade Wheel Diameter (In.)7-3/8
  • Blade Size (In.)1/2 x 0.025 x 64-1/2
  • Bed Height (In.)28
  • Motor (HP)1/2 HP, 115V, Single Phase
  • Weight (Lbs.)147
  • Overall Dimensions (L x W x H) (In.)38.58 x 20.47 x 47.3 (bow lowered)
  • Overall Assembled (Bow Lowered) (L x W x H)38.58 x 20.47 x 47.3
  • Shipping Weight (Lbs.)147
