Jet 354170 JDP-20MF, 20" Floor Drill Press 115/230V 1Ph

Jet Tools

$1,499.00
(No reviews yet) Write a Review
SKU:
JT354170
UPC:
662755104121
Adding to cart… The item has been added

Accuracy, stability and versatility are the benchmark features of the JET 15" and 20" Drill Presses. This high quality line of JET Drill Presses offer a greater range in spindle speeds than other machines of this class. JET backs their machines with the industry-leading Two Year Warranty.

Features:

  • Hinged metal belt and pulley cover
  • Quick adjustment motor mount for rapid changing of spindle speeds
  • Rotating, 45° tilting, crank operated worktable with release clamp
  • On/off switch located on front of drill press head
  • 1/2" diameter external depth stop with three nut locking feature for quick adjustment
  • Adjustable tension spindle return spring
  • Spindle is supported by high quality bearings
  • Built-in work lamp (bulb not included)
  • Drill chuck and key included
  • Telescoping safety spindle guard



Specifications:

  • Style (Type) Variable
  • Drills to Center of Circle (in) 20
  • Drilling Capacity Cast Iron (In.) 1
  • Drilling Capacity Mild Steel (In.) 3/4
  • Distance Column to Spindle (In.) 10
  • Number of Spindle Speeds 12
  • Range of Spindle Speeds (RPM) 150 - 4,200
  • Column Diameter (In.) 3-3/8
  • Spindle Taper (In. x TPI) MT-3
  • Spindle Travel (In.) 4-5/8
  • Spindle Distance to Base (In.) 46-3/4
  • Spindle Distance to Table (Max.) (In.) 29-1/8
  • Table Size (L x W) (In.) 18-1/2 x 16
  • Table Travel (In.) 21-1/2
  • T-Slots Number and Size (In.) 6 & 1/2
  • T-Slot Centers (In.) 3-1/2
  • Work Table Weight Capacity (Lbs.) 80
  • Base Dimensions (In.) 13-3/4 x 22-3/4
  • Base Work Table (In.) 13 x 8-1/2
  • Base Slots Number & Size (In.) 2 & 5/8
  • Motor (HP) 1-1/2 HP, 115/230V, 1 Ph
  • Prewired (V.) 115
  • Overall Dimensions (L x W x H) (In.) 33-1/2 x 18-1/2 x 67
  • Weight (Lbs.) 282
