If you do any kind of production ripping or milling, you know what a big chore it can be feeding by hand, especially with longer and wider stock. For those who want to increase production, upgrade, or add on another stock feeder, we have a power feeder to match virtually any application and budget.
Made in an ISO 9001 factory
FEATURES:
- Track feed with four speeds and forward/reverse
- Track is spring tensioned with 3/4" suspension
- Heavy-duty gear reduction with hardened gears
- X-, Y-, Z-axis adjustment
- 1-year warranty
SPECIFICATIONS:
- Motor: 1 HP, 220V, single-phase, 7.7A
- Feed speeds: (4) 14.5, 29, 39, 78 FPM
- Rotation: Forward & reverse
- Max. height of track: 8-1/2"
- Min. workpiece length: 8"
- Horizontal travel: 24-1/4"
- Swing: 360°
- Track: (3 pieces) synthetic rubber, 1/2" x 44"
- Track suspension: 3/4"
- Approx. shipping weight: 150 lbs.
