Get two machines in one with this combination planer/moulder!
If you make your own moulding and casings, or would like to, the G1037Z 13” Planer / Moulder will save you valuable shop space, time and money. Use it to plane your stock to the desired thickness, then easily convert it to a moulder to create nearly any profile you can imagine.
The 1-1/2 HP TEFC motor provides plenty of power for planing or moulding while the 4" dust port allows easy connection to a dust collector. The undermount motor makes for convenient knife changes, while the easily adjustable guides and dual moulding fences make creating architectural moulding and casings a breeze.
Planing max capacity is 1/8" deep and up to 13" wide.
Moulding max capacity is 3/4" deep and up to 4-9/16" wide.
This dual-purpose machine combined with a low price and its capability will more than pay for itself —and fast!
Like all Grizzly machines, the G1037Z comes with a 1-year warranty which covers parts and assures the unit is free from factory defects. (Knives and other consumables are not covered by the warranty.)
The G1037Z manual was written by our U.S. based Technical Documentation Department and is packed with useful information.
The Grizzly Technical Support team is U.S. based. Parts and accessories are available online and shipped from the Grizzly parts warehouse in Springfield, MO.
Made in an ISO 9001 factory
SPECIFICATIONS:
- Motor: 1-1/2 HP, 110V/220V (prewired 110V), single-phase, 15/7.5A
- The maximum cutting width is 13".
- The maximum lumber height is 6".
- The maximum cutting depth is 1/8" (planing).
- The maximum profile depth is 3/4" (moulding).
- The maximum width capacity is 4-9/16" (moulding).
- The planing feed rate is 24 FPM.
- The moulding feed rate is 12 FPM.
- 3 HSS knives at 13" x 5/8" x 1/8"
- Cutterhead speed: 5000 RPM
- Footprint: 22-1/4" x 21-1/4"
- Approximate shipping weight: 236 lbs.
FEATURES:
- Precision-ground cast-iron table
- 4" dust port
- Rubberized steel feed rollers
- Powder coated paint
- Includes floor stand
