Features
- Taiwan Machines
- ISO 9001 certified
- Hydraulic adjustment for opening
- Hydraulic power clamping for workpiece
- 26” manual back gauge with handwheel
- 1” manual beam adjustment (front and back)
- reverse bend is ¾” (20mm)
- Heavy welded all steel construction for maximum rigidity
- Hydraulic logic system centrally located and quiet
- A wide guide body ensures strong, stable, smooth & accurate movement
- Total pieces fingers assortment: 3”/ 3pcs, 4”/2pcs, 5”/5pcs and 6”/1pc
- Central control panels on each side for convenient operation
- Jog and auto operation modes
- Overload protection and disconnect switch
Standard Equipment
- Assorted fingers
- 26” manual back gauge with one side handwheel operation
- Angle set up dial
- Hydraulic clamping system
- Foot pedal control for hydraulic clamping & auto mode
Specifications
- Max Bending Length: 4’
- Capacity Mild Steel: 10 Ga
- Capacity Stainless Steel: 12 Ga
- Bend Angle Degree: 135°
- Max Box Depth: 6”
- Large Beam Opening: 3”
- Oil Tank: 10 Gal
- Main Motor: 5 HP
- Machine Weight: 4,150 lbs
- Overall Dimensions: 88 x 51 x 67
