- Taiwan Machines
- ISO 9001 certified
- Hydraulic adjustment for opening
- Hydraulic power clamping for workpiece
- 26” manual back gauge with handwheel
- 1” manual beam adjustment ( front and back )
- Min. reverse bend is ¾” (20mm)
- Heavy welded all steel construction for maximum rigidity
- German Rexroth Hydraulic logic system centrally located and quiet
- A wide guidebody ensures strong, stable, smooth & accurate movement
- Total pieces fingers assortment:
- 3”/6pcs, 4”/4pcs, 5”/10pcs, 6”/6pcs
- Central control panels on each side for convenient operation
- Jog and auto operation modes
- Overload protection and disconnect switch
- One year warranty for parts
- Assorted fingers
- 26” manual back gauge with one side handwheel operation
- Angle set up dial
- Hydraulic clamping system
- Foot pedal control for hydraulic clamping & auto mode
Max Bending Length:
10'
Bending Capacity:
Mild Steel
Stainless Steel
14 Ga.
16 Ga.
Hemming max thickness:
28 Ga.
Bend Degree:
135
Max. Box Depth:
6"
Large Beam Opening:
3"
Manual Back Gauge:
26”
Oil Tank Gal.
17 Gal
Hydraulic Oil:
Shell #68 or equivalent
Main Motor
5 HP 3 Phase
Prewired: 220VAC 20A
Optional: 440VAC 10A
Weight
6,850 lbs.
Shipping Weight:
6,950 lbs.
Overall Dimensions
142" x 46" x 66"
Shipping Dimensions:
153” x 41” x 67”
