Edwards 120 Ton Ironworker 380V, 3PH, 50HZ With Powerlink

Edwards 120 Ton Ironworker 380V, 3PH, 50HZ With Powerlink

Edwards

$45,999.00
(No reviews yet) Write a Review
SKU:
ED9-IW120-3P380-A
UPC:
731325555967
Adding to cart… The item has been added

Our most powerful Ironworker, the 120 Ton, offers the largest capacity and most flexibility - created with heavy-duty Made in USA steel construction. This compact machine allows for fast and easy transitions between fabrication operations. The 5 Workstations include a punch, flat bar shear, angle shear, coper notcher, and Open Cavity that accepts 4 Attachments. Further customize the Ironworker to your projects with 12 additional Attachments and 15 Accessories. Other features include an electric foot pedal with integrated jog control and bright LED lights to increase visibility. In addition, the PowerLink™ System increases your capabilities by turning your Ironworker into a power source for our line of Hydraulic Tools. The longer stroke length and increased capacity provided by this Ironworker allow it to handle the most heavy-duty projects.

Adjustable electric stoke control
Angle Shear blades have 2 corner radii for both thin and thick material and are made of precision tool steel with 2 cutting edges for extended life
ANSI B11.5-1988(02) Compliant Guarding
ETL Certified Controls
Flat Bar Shear blades are made of precision machined, high-quality tool steel with 4 cutting edges for extended life
Integrated Lock-out/Tag-out system with multiple location E-Stop (foot pedal & control panel) for added safety
Optimized workstation heights for improved efficiency
Punches are easily changeable, long-lasting and available from 1/8" to 4" diameters along with square, oblong, hex, metric, and custom shapes
Vertical movement produces even pressure resulting in precise punching and shearing with minimal distortion that results in extended tooling life


Stock Number ED9-IW120-3P380-A
Amps 16.4
Angle Iron Capacity (Size/Min Dia.) 6 x 6 x 1/2
Angle Shear Max Capacity 1/2" 6 x 6
Angle Shear Max Capacity (In.) 6 x 6 x 1/2
Angle Shear Work Height (In.) 52-1/2
Coper Notcher Max Capacity (In.) 3 x 6 x 1/2
Coper Notcher Work Height (In.) 40
Flat Bar Shear Max Capacity 1" 12
Flat Bar Shear Max Capacity 1/2" 24
Flat Bar Shear Max Round Capacity (In.) 1-1/4
Flat Bar Shear Max Round (In) 1-1/4
Flat Bar Shear Max Square (In) 1-1/4
Flat Bar Shear Rating (Tons) 120
Flat Bar Shear Work Height (In.) 33-1/4
Gross Weight (Lbs) 5975
Hydraulic Pump (GPM) 24
Hydraulic Reservoir (Gal.) 17
Hydraulics (GPM) 24
Hydraulics (PSI) 3800
Model Number IW120-3P380-AC900
Motor Amps 16.4
Motor (HP) 10 HP 3 ~ 380V, 50 Hz
Motor Speed (RPM) 1770
Overall Dimensions (L x W x H) (In.) 60 x 60 x 84
Product Dimensions (In.) 60 x 60 x 84
Prop 65 Cancer and Reproductive Harm
Punch Max Capacity (In.) 1-1/2 diam. in 1 mild steel
Punch Open Height (In) 9-1/8
Punch Rating (Tons) 120
Punch Shut Height (In) 7-1/8
Punch Stroke (In.) 2
Punch Work Height (In.) 36-5/8
Rating (Tons) 120
Reservoir (Gal.) 17
Shipping Dimensions (L x W x H) (In.) 60 x 67 x 87
Valve Pressure (PSI) 3800
Weight (Lbs.) 5500

!
