Edwards 120 Ton Ironworker 230V, 3PH

Edwards 120 Ton Ironworker 230V, 3PH

Edwards

$43,499.00
(No reviews yet) Write a Review
SKU:
ED9-IW120-3P230
UPC:
731325555936
Adding to cart… The item has been added

Our most powerful Ironworker, the 120 Ton offers the largest capacity and most flexibility for a durable and heavy-duty design made in the USA. The 5 Workstations include a Punch, Flat Bar Shear, Angle Shear, Coper Notcher, and Open Cavity that accepts 4 Attachments. This compact machine allows for fast and easy transitions between fabrication operations. Further customize the Ironworker to your projects with 12 interchangeable Attachments and 15 optional Accessories. The longer stroke length and increased capacity provided by this Ironworker allow it to handle the most heavy-duty projects.

Adjustable electric stoke control
ANSI B11.5-1988(02) Compliant Guarding
Bright LED lights increases visibility
Electric foot pedal with integrated jog control
ETL Certified Controls
Integrated Lock-out/Tag-out system with multiple location E-Stop (foot pedal & control panel) for added safety
Optimized workstation heights for improved efficiency
Punches are easily changeable, long-lasting and available from 1/8" to 4" diameters along with square, oblong, hex, metric, and custom shapes
Vertical movement produces even pressure resulting in precise punching and shearing with minimal distortion that results in extended tooling life


Stock Number ED9-IW120-3P230
Amps 26
Angle Shear Max Capacity 1/2" 6 x 6
Angle Shear Max Capacity (In.) 6 x 6 x 1/2
Angle Shear Work Height (In.) 52-1/2
Coper Notcher Max Capacity (In.) 3 x 6 x 1/2
Coper Notcher Work Height (In.) 40
Flat Bar Shear Max Capacity 1" 12
Flat Bar Shear Max Capacity 1/2" 24
Flat Bar Shear Max Round Capacity (In.) 1-1/4
Flat Bar Shear Max Round (In) 1-1/4
Flat Bar Shear Max Square (In) 1-1/4
Flat Bar Shear Rating (Tons) 120
Flat Bar Shear Work Height (In.) 33-1/4
Gross Weight (Lbs) 5975
Hydraulic Pump (GPM) 24
Hydraulic Reservoir (Gal.) 17
Hydraulics (GPM) 24
Hydraulics (PSI) 3800
Model Number IW120-3P230
Motor Amps 26
Motor (HP) 10 HP 3 ~ 230V
Motor Speed (RPM) 1770
Overall Dimensions (L x W x H) (In.) 60 x 60 x 84
Product Dimensions (In.) 60 x 60 x 84
Prop 65 Cancer and Reproductive Harm
Punch Max Capacity (In.) 1-1/2 diam. in 1 mild steel
Punch Open Height (In) 9-1/8
Punch Rating (Tons) 120
Punch Shut Height (In) 7-1/8
Punch Stroke (In.) 2
Punch Work Height (In.) 36-5/8
Rating (Tons) 120
Shipping Dimensions (L x W x H) (In.) 60 x 67 x 87
Weight (Lbs.) 5500

!
