Dake Bench Model Drill Press - TB-16V

Bench top variable speed drill press that is ideal for cell applications requiring fast tooling changes. Featuring a locking handle hub for repeatable depth, CE safety electrical package, a large diameter sturdy spindle, and a massive

cast head. The speed can be easily adjusted while drilling by turning the large selector knob on the top of the drill.


Features:

  • A locking handle hub with convenient dial-in adjustment and an easy to read scale for fast, accurate, and repeatable depth setting changes.
  • Large diameter sturdy spindle for rigid drilling has four bearing points for smooth operation.
  • Bench and floor models both have machined table and base surfaces with t-slots for mounting and fixturing.
  • Top mounted speed selector knob with convenient speed range indicators allows operator to dial in optimal speed range.
  • CE safety electrical package features push button on/off switch, emergency stop button, low voltage controls, thermal overload, and interlock safety switch for belt cover.
  • Massive cast head, machined column, and sturdy cast base reduces vibration.
  • Quick bit changes with standard Morse Taper (MT), common adaptors or standard keyed chuck.
  • Handle has 3 spokes with spring return for precise operator control and ergonomic operation.



Standard Equipment:

  • ½” Keyed chuck
  • Drift for bit removal
  • Plexiglas chip and chuck guard




Specs:

  • Model: TB-16V
  • Number: 977102-1
  • Drill capacity: 5/8”
  • Horsepower: 1/2
  • Motor: n/a
  • Spindle taper: MT2
  • Working diameter: 14-1/8”
  • Number of speed: Mechanical variator
  • Spindle speed range: 545-4,000 rpm
  • Electrics: 110V 1PH
  • Weight: 175 lbs
  • Spindle travel: 3-1/8”
  • Column diameter: 3-1/8”
  • Table depth: 11-3/4”
  • Table width: 11-3/4”
  • Base depth: 17-3/4”
  • Base width: 12-1/4”
  • Spindle to table: 16-1/2”
  • Spindle to base: 26-1/2”
  • Overall height: 42-1/2”
