The WP-750 welding positioner from Baileigh Industrial is built to last using only the best components. This 110 volt powered pipe welding machine has a 770lb capacity in the vertical position and a 385lb capacity in the horizontal position. It is very easy to use with its foot pedal control and variable speed.
Welding positioners are great for any fabrication shop as it helps save time and money by reducing the handling of parts and almost eliminating the waste caused by inaccurate welds. For more information contact a Baileigh Industrial representative.
- Table capacity 770 lbs
- Variable speed
- 110Vu Foot pedal operated
- Easy to use manual tilt
- 135° of tilt
- 13" turn table
SPECIFICATIONS
| Item Number | WP-750 |
|---|---|
| Vertical Capacity | 770 lbs. |
| Horizontal Capacity | 385 lbs. |
| Range of Movement | 0 to 135 Degrees |
| Turntable Size | 13" |
| Speed | 0.3 to 4 rpm |
| Maximum Current | 300 Amps |
| Drive | Foot Pedal |
| Power | 110V |
| Shipping Weight | 175lbs |
| Max. Burst Current | 500 Amp. |
| Shipping Dimensions (Inches) | 23x23x23 |
