This electric slip roll can save time and effort in any HVAC shop or general fabrication shop. Its solid plate steel upper main frame is precisely machined to keep all 3 rolls in alignment.
- 50” working width.
- Can roll 16 gauge mild steel with ease.
- 1 hp motor runs on 220-volt single-phase power.
- Motor controls the movement of 2 driven rolls, so the SR-5016 has enough power for almost any job, anywhere.
- Includes foot pedal for both left and right rolling applications.
- All-steel lower base is fully welded and integrated with the uprights for rigidity.
- Comes with 3 grooves for rolling wire or rod.
- Integrated emergency stops to help maintain a safe workplace.
- Covered by a 1-year parts warranty.
- You can count on lifetime technical support by phone from our team of reps with hands-on machine experience.
SPECIFICATIONS
| Item Number | SR-5016 |
|---|---|
| Forming Width | 50" |
| Roll Speed | 16 rpm. |
| Upper Roll Dia. | 3" |
| Minimum Forming Dia | 4.5" |
| Motor | 1 hp |
| Wire Grooves | Yes |
| Stand | Yes |
| Capacity (Mild Steel) | 16 ga. (.060") |
| Power | 220V / 1-phase |
| Shipping Weight | 870lbs |
| Shipping Dimensions (Inches) | 70x23x44 |
