Built from steel and cast iron, this semi-automatic cold saw will last for decades. All industrial-grade components, like the gearbox, hydraulics, and coolant system, keep cuts accurate.
Recommended for: Large-scale production at any full-service fabrication or machine shop.
Miters 45° left and 60° right, perfect for angle iron and channel and comes with a box of tools for maintenance and blade changeovers - Metered stop rod lets you easily make repeatable lengths for production runs
Features include: 5 hp blade motor runs on 220-volt 3-phase power, 4 cutting speeds (35, 60, 70, and 120 rpm), and accepts a maximum 17” blade
Cutting head rides up and down heavy slideway tracks, hardened and ground to offer the most accurate cuts in the industry with help from the rugged steel base that reduces vibrations to produce burr-free cuts like only a cold saw can
Other features include: Blade head allows you to adjust the descent speed, turn a dial for manual or semi-automatic mode, and adjustable gibs on the column give the slideways a long lifetime of use
You can set a hard vertical stop so that the blade only cuts so far down—great for faster cycle times while the hydraulic self-centering vise clamps the material, then the saw starts its descent
Whole carriage, including motor and blade, will slide up or down with the press of a button so you can get your material in there
Hydraulic downfeed movement of the cutting head offers precise cutting pressure through the cycle, which extends blade life
Simple to operate: put the material against the stop rod and press the foot pedal to start cutting and after the cut the blade automatically shuts off and returns to home position
Flood coolant system prolongs blade and machine life, plus it helps the blade give you cuts with smooth edges while the industrial-grade coolant pump cools the blade and washes chips away
Oiler system lets you pump a lever to release oil from the reservoir and keep the head moving up and down without catching
Stock Number BA9-1002633
Model Number CS-C425SA
Motor (HP) 5 hp
Prop 65 Cancer and Reproductive Harm
Solid Round at 45 Degrees (In.) 2.36"
Solid Round at 90 Degrees (In.) 2.75"
Style (Type) Single Action
Tubing Rectangle at 45 Degrees (In.) 3.93" x 1.96"
Tubing Rectangle at 90 Degrees (In.) 4.72" x 1.96"
Tubing Round at 45 Degrees (In.) 4.5"
Tubing Square at 45 Degrees (In.) 3.93" x 3.93"
Tubing Square at 90 Degrees (In.) 4.92"
Weight (Lbs.) 1870
