Baileigh Radius Bender R-M7

Baileigh Industrial

$839.00
(No reviews yet) Write a Review
SKU:
BA9-1006861
UPC:
731325411706
Adding to cart… The item has been added

The portable radius bender R-M7 is built from quality steel (unlike most competing roll benders in this price range) and can bend tube and pipe to large radii.



  • Bends 1.5” pipe to a minimum radius of 20” and 2” round tube to a minimum radius of 60”.
  • Manual crank makes quick work of large radius bends*.
  • Shafts turn on precision ball bearings for the smoothest possible operation.
  • Many different tooling options, available from Baileigh, enable the machine to tackle a wide range of projects
  • Takes up little space and will easily fit into even the smallest shops.
  • Includes a set of 1-1/2" OD tube dies.
  • Baileigh covers this tubing roller with a 1-year parts warranty and lifetime technical support by phone.



*Please note that the R-M7 steel roll bender is not for rolling complete circles.





SPECIFICATIONS

Item Number R-M7
Roll Adjustment Manual
Pipe Capacity Size: 1.5" / Min. Radius: 20"
Round Tube Capacity Size: 2" / Min. Radius: 60"
Shaft Center Distance Adj. (lower rolls)
Rectangle Capacity Size: 1 x 2" / Min. Radius.: 10"
Pinch Single
Capacity Flat Bar Size: 1.25" / Min. Radius.: 10"
Power Manual
Shipping Weight 83lbs
Material Type All Specs based on 60,000 PSI (42 Kg/mm 2) Tensile Strength – Mild Steel.
*Optional Tooling Some applications may require optional tooling. Please contact a Technical Sales Specialist at Baileigh Industrial with specific application details.
Shipping Dimensions (Inches) 26x10x19
