Baileigh Cnc Roll Bender R-Cnc45

Baileigh Industrial

Was: $42,999.00
Now: $36,549.15
(No reviews yet) Write a Review
SKU:
BA9-1006760
UPC:
731325077377
Adding to cart… The item has been added

The most compact model in our CNC ring roller line, this double-pinch tube bender ensures accuracy and minimizes flex with an electro-welded steel plate framework.


  • Runs on 220-volt 3-phase power.
  • Bends up to 2.5" round tube and 2” schedule 40 pipe.
  • Efficient double-pinch design includes 3 driven rolls.
  • You can control the roll speeds—4 speeds on top roll and 2 speeds on bottom rolls—to suit the needs of particular project.
  • Choose between progressive (profile moving) or direct (profile stopped) top roll movement.
  • Hydraulic lateral guide rolls, with angle-correcting tools, calibrate to accept 75 different profiles.
  • Arc meter radius gauge eliminates scrap material at the beginning and ends of bent pieces, reducing costly waste.
  • Interchangeable bottom rolls increase versatility.
  • Touchscreen control mounted on podium combines intuitive design with industrial-grade durability.
  • Internal memory stores up to 40 programs with 24 bends per program.
  • This pipe bender comes covered by a 1-year parts warranty and lifetime technical support by phone.

Why choose the R-CNC45 over similar machines?


  • Components from some of the industry's top manufacturers, including Rexroth and Schneider Electric ensure that the machine delivers precise results you can depend on.
  • Interchangeable bottom rolls prevent material deformation or wrinkling and solve tricky extrusion problems.
  • You won’t find many roll benders on the market with the rugged steel construction of the R-CNC45.
  • Bend pattern storage saves time on multiple production runs. We can even customize the memory to hold even more information.
  • You can count on Baileigh’s team of experienced reps for troubleshooting and application tips—always just a call away.



SPECIFICATIONS

Item Number R-CNC45
Driven Rolls 3
Roll Adjustment Hydraulic
Pipe Capacity Size: 2" (sch. 40) / Min. Dia.: 80"
Round Tube Capacity Size: 2.5" (.100") / Min. Dia.: 60"
Square Tube Capacity Size: 2.00" (.110")
Flat Bar Easy Way Size: 3.5" (.50") / Min. Dia. 32"
Flat Bar Hard Way Size: 3.15" (.375")/ Min. Dia.: 32"
Angle Iron Capacity Size: 2" (.196") / Min. Dia.: 24"
Shaft Diameter 1.77"
Shaft Center Distance Adj. (lower rolls)
Upper Roll Dia. 6.693"
Lower Roll Dia. 6.693"
Motor 7.4 hp
Pinch Single with Interchangeable Bottom Rolls
Digital Readout Yes
Power 220V 3- phase
Shipping Weight 1728lbs
*Optional Tooling Some applications may require optional tooling. Please contact a Technical Sales Specialist at Baileigh Industrial with specific application details.
Dimensions L x W x H 48" x 30" x 58"
